Smart, Seamless CIPP Applications: Structural and Functional Solutions
Cured-In-Place Pipe (CIPP) is a cutting-edge trenchless repair technique that creates a new, seamless—without digging or disrupting the surface. Using a resin-saturated liner that’s cured inside the existing pipe, it restores structural strength, seals leaks, and extends pipeline life by decades.
On this page, you’ll discover where CIPP is used, how it works, and why it’s the go-to solution for gas, Pipe, stormwater, and water pipeline rehabilitation.
Where Is CIPP Used?
Cured-In-Place Pipe (CIPP) is a trenchless rehabilitation technology ideal for repairing a variety of underground pipelines without digging. Typical applications include gas, Pipe, stormwater, and water systems:
1
Gas Pipe Repair
CIPP is well-suited for rehabilitating gas distribution pipelines, typically up to 1.5 m diameter. The process uses pressure-rated liners (epoxy, polyurethane, fiberglass) to restore integrity and prevent leaks.
2
Pipe (Sanitary) Repair
One of the most common uses—CIPP restores structural strength and forms a seamless barrier against root intrusion, cracking, and infiltration in sanitary pipe mains. It works for pipes ranging from residential laterals (2″–8″) to large pipes up to 2.8 m.
3
Stormwater (Drainage) Pipe Repair
CIPP is also deployed for stormwater culverts, drainage, and storm pipes, improving water flow and sealing leaks. Aside from structural benefits, it reduces sediment buildup and environmental contamination.
4
Drinking & Potable Water Pipe Repair
Highly effective for pressurized water and potable-water mains, often using epoxy-lined felt/fiberglass laminates rated for pressure (e.g., 250 psi). Maintains drinking water quality with minimal downtime.
5
Firefighting Pipelines
Pressurized water lines for firefighting systems in high-rise buildings or malls.
Pipe Types: MS (Mild Steel) , GI
CIPP Use: Suitable for internal rehabilitation where leakage or corrosion has started.
6
Industrial Process Pipes (in Factories)
Transport of chemicals, effluents, or process water.
Pipe Types: Steel , FRP , HDPE
CIPP Use: Chemical-resistant liners can be used for harsh environments.
7
Basement or Underground Drainage Pipes
Collecting grey/black water or stormwater from parking or basements.
Pipe Types: Cast Iron , RCC
CIPP Use: Fixes hidden pipe failures without damaging floors or structures.
How It’s Done
1
Inspection & Cleaning
CCTV/hydro‑jetting for blockages and condition assessment.
2
Liner Preparation
Custom felt/fiberglass tube impregnated with resin on-site.
3
Installation
Inversion or pull-in using air/hydro pressure.
4
Curing
Choose between steam, hot water or UV light based on application.
5
Connection & Testing
Reinstate laterals with robotic cutters, pressure test, QA/QC measures using ASTM/ISO standards.
Benefits & Use Cases
- Minimal Disruption: No trenches; installed via existing access points—ideal in sensitive or urban environments.
- Structural Integrity: Fully structural liners extend pipe life by 50+ years.
- Hydraulic Efficiency: Smooth liners increase flow and reduce friction (approximately 30% improvement).
- Prevents Leakage & Intrusion: Acts as a robust barrier to roots and groundwater.
- Cost & Time Saving: Lower lifecycle costs than excavation; installation often completes in less than 24 hours.
- Environmentall Friendly: Reduces emissions and minimizes site disturbance.
What services does Pipe Care Services Pvt. Ltd. offer?
Pipe Care Services specializes in advanced CIPP (Cured-In-Place Pipe) lining, Pipe rehabilitation, blockage removal, grease and oil deposit cleaning, line collapse management, and trenchless technology implementation. We also provide emergency drainage services to residential, commercial, and industrial clients across Delhi NCR.
What is CIPP and how does it work?
CIPP (Cured-In-Place Pipe) is a trenchless rehabilitation method used to repair damaged pipelines without digging. A resin-saturated liner is inserted into the existing pipe and cured using hot water, steam, or UV light. Once cured, it forms a new pipe inside the old one — restoring structural strength, flow, and longevity without disrupting the surface above
What pipe sizes can you rehabilitate using CIPP?
Cured-In-Place Pipe (CIPP) technology is a highly adaptable, trenchless solution that works effectively across a wide range of pipe sizes, materials, and shapes. At Pipe Care Services, we provide CIPP lining for pipelines ranging from 30mm and more, covering both residential and industrial needs. Our system is compatible with various pipe materials, including PVC, HDPE, cast iron, clay, concrete (RCC), steel, galvanized iron, and asbestos cement. CIPP can also be applied to multiple pipe shapes such as circular, oval (egg-shaped), and even some rectangular or custom-profiled lines, depending on site conditions. This flexibility makes it ideal for underground pipelines, internal drainage systems, and complex Pipe networks — all without the need for digging or major disruption.
What regions do you operate in?
Pipe Care Services currently operates across the Delhi NCR region, including Delhi, Noida, Gurugram, Ghaziabad, Faridabad, and Greater Noida. We serve housing societies, malls, hotels, hospitals, and more with fast and reliable drainage solutions.
How experienced is your team?
Our team brings over 17 years of combined industry experience, trained under our parent company Onsite India Pvt. Ltd. All technicians are highly skilled in trenchless technology and follow strict safety and quality standards to ensure effective, long-lasting results.
How do you ensure project quality and safety?
We follow international safety standards, use certified equipment and high-grade materials, and conduct regular site inspections and quality checks. Our team is trained in confined space entry, PPE compliance, and emergency response protocols to maintain the highest levels of safety and quality throughout every project.
